Cell image gallery
Diagnosis of AML in the bone marrow: Characteristic are bundles of Auer rods (->) and many atypical promyelocytes.
<p>Diagnosis of AML in the bone marrow: Characteristic are bundles of Auer rods (->) and many atypical promyelocytes.</p>
During the preparation of a large number of blood films for EQA purposes, the blood drop on the slide had already started to dry prior to smearing, so that, when the blood film was made, many white blood cells were pulled towards the edge, resulting in disturbed cell distribution.
<p>During the preparation of a large number of blood films for EQA purposes, the blood drop on the slide had already started to dry prior to smearing, so that, when the blood film was made, many white blood cells were pulled towards the edge, resulting in disturbed cell distribution.</p>
Doehle bodies were named after the German pathologist Karl Gottfried Paul Döhle (1855-1928). They are defined as light blue-grey oval inclusions with a diameter of 1 to 3 µm located in the peripheral cytoplasm of mature and immature neutrophils. The structures are seemingly derived from the rough endoplasmic reticulum and hence contain RNA. They are often present in conjunction with toxic granulation.
<p>Doehle bodies were named after the German pathologist Karl Gottfried Paul Döhle (1855-1928). They are defined as light blue-grey oval inclusions with a diameter of 1 to 3 µm located in the peripheral cytoplasm of mature and immature neutrophils. The structures are seemingly derived from the rough endoplasmic reticulum and hence contain RNA. They are often present in conjunction with toxic granulation. </p> <p> </p>
At low magnification, a drop of saliva is easily detected. When enlarged considerably, it might cause confusion.
<p>At low magnification, a drop of saliva is easily detected. When enlarged considerably, it might cause confusion.</p>
Large number of echinocytes of a healthy individual resulting from prolonged storage of the EDTA blood (48 hours).
<p>Large number of echinocytes of a healthy individual resulting from prolonged storage of the EDTA blood (48 hours).</p>
Echinocytes ('sea urchin cells') of a healthy individual resulting from prolonged storage of the EDTA blood (24 hours).
<p>Echinocytes ('sea urchin cells') of a healthy individual resulting from prolonged storage of the EDTA blood (24 hours).</p>
The edge of a correctly prepared blood film from a normal blood sample. Relatively few white blood cells can be seen in this example.
<p>The edge of a correctly prepared blood film from a normal blood sample. Relatively few white blood cells can be seen in this example.</p>
The endothelial cells are part of the vascular wall, which was damaged during venepuncture. (Blood coagulation was activated during the process: on the bottom left a fibrin fibre can be recognised.)
<p>The endothelial cells are part of the vascular wall, which was damaged during venepuncture. (Blood coagulation was activated during the process: on the bottom left a fibrin fibre can be recognised.)</p>
Size: 12-17 µm
Nucleus: usually bilobed with visible filament
Cytoplasm: weekly basophilic containing coarse reddish-orange granulation packing the cytoplasm
Function: Phagocytosis, chemotaxis, mortification of parasites, inhibition of mastcell degranulation, eutralization of histamine
<p>Size: 12-17 µm </p> <p>Nucleus: usually bilobed with visible filament </p> <p>Cytoplasm: weekly basophilic containing coarse reddish-orange granulation packing the cytoplasm </p> <p>Function: Phagocytosis, chemotaxis, mortification of parasites, inhibition of mastcell degranulation, eutralization of histamine</p>
